- 彈簧加載靈活,壓力釋放後自動下降。
- 每個項目附加2個加長墊,長度:46毫米/ 72毫米。
- Flexible spring loaded, automatically down after pressure released.
- 2 pcs extended mat attached for each item, LENGTH: 46mm/72mm.
ITEM | 能力(Capacity) | 揚程 (lift) | 本身高(height) | 伸長總高 (max height) | 主軸直徑(Diameter) | 底座尺寸(base dimensions LxW(mm) | 輔助墊 Auxiliary (mm) | Weight(kgs) |
CJ201 | 20 TON | 90 | 200 | 290 | 55 | 125x190 | 46/72 | 15.5 KG |
CJ202 | 20 TON | 145 | 245 | 390 | 55 | 125x190 | 46/72 | 17 KG |
CJ301 | 30 TON | 90 | 200 | 390 | 75 | 162x220 | 46/72 | 23 KG |
CJ302 | 30 TON | 145 | 245 | 290 | 75 | 162x220 | 46/72 | 25 KG |
